Why do we support unaligned/narrow transfer
Overview
As a mainstream on-chip bus protocol, AXI4 defines two special transfer mechanisms in addition to standard aligned transfers: Unaligned transfer and Narrow transfer.
-
Unaligned transfer refers to scenarios where the address is not aligned with the bus width.
-
Narrow transfer specifically refers to scenarios where the data width is less than the bus width.
Motivation
In practical engineering implementations, commercial IP solutions leverage AXI bus crossbar matrices to automatically handle address alignment and width conversion. However, when adopting open-source IP solutions, significant functional limitations emerge:
-
Inability to guarantee comprehensive handling of all corner cases.
-
Potential absence of critical crossbar module support.
Rationale
As disclosed in Intel’s technical documentation, the configurable support for unaligned transfers in commercial IPs inherently reflects a trade-off between resource utilization and functional completeness.
For the current design, the additional hardware resource overhead introduced to support unaligned/narrow transfer mechanisms remains within acceptable margins. Notably, the maximum operating frequency of the SDRAM controller is constrained by the physical limitations of the SDRAM device itself (≤ 200 MHz). This ensures that even with added logic for corner case handling, no timing closure issues or performance degradation will occur.
From a protocol compliance perspective, claiming adherence to the AXI4 standard while selectively omitting protocol-defined special transfer mechanisms raises concerns about standard conformance. Such selective support effectively equates to defining a new bus subset (e.g., an AXI4 without unligned/narrow transfer variant), which violates engineering best practices and diminishes IP interoperability.
We have been working hard to ensure that our design is capable of being plug-and-play, covering all possible scenarios. Therefore, this design fully implements the AXI4 protocol specification to ensure comprehensive support for all transfer modes.
